Outdoor LED Display Screen with Die Cast Aluminum Cabinet Full Color and High Brightness for Advertising
Detalhes do produto:
| Lugar de origem: | Guangdong, China |
| Marca: | LEDKING or OEM & ODM |
| Número do modelo: | FO-P5/6.67/8/10 |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 1 |
|---|---|
| Preço: | $456-476 |
|
Informação detalhada |
|||
| Pitch de pixel: | 5 mm, 6 mm, 6,67 mm | Densidade de pixels: | 40.000 pontos/m2, 27.777 pontos/m2, 22.477 pontos/m2 |
|---|---|---|---|
| Configuração do pixel: | 1r1g1b | Consumo máximo de energia: | 40W, 29W, 43W |
| Peso do painel: | 0,45kg, 0,35kg, 0,45kg | Tamanho do gabinete: | 960mm*960mm*90mm, 576mm*576mm*90mm, 768mm*768mm*90mm |
| Resolução do gabinete: | 192 pontos * 192 pontos, 96 pontos * 96 pontos, 128 pontos * 128 pontos, 144 pontos * 144 pontos | O melhor ângulo de vista: | 170/120, 140/120 |
| Fonte de alimentação da tela: | AC110V/220V - 5V60A | Capacidade máxima de energia: | 976W/m2, 1050W/m2, 1350W/m2 |
| Frequência de atualização: | 1920-3840 HZ/S | Brilho: | 5.000-5.500 mcd/m2, 4.000-5.000 cd/m2 |
| Distância de controle: | <100 milhões | Temperatura operacional: | -10°C~45°C |
| Umidade operacional: | 10-90% | ||
| Destacar: | Die Cast Aluminum Cabinet LED Video Wall,Full Color Outdoor LED Display Screen,High Brightness Digital Signage Billboard |
||
Descrição de produto
960×960 P5 P6.67 P8 P10 Fixed Outdoor LED Video Wall Display
Product Specifications
Module Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Panel Dimension | 320mm(W) × 160mm(H) | 192mm(W) × 192mm(H) | 320mm(W) × 160mm(H) |
| Pixel pitch | 5mm | 6mm | 6.67mm |
| Pixel Density | 40000 dot/m² | 27777 dot/m² | 22477 dot/m² |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD3535 | SMD3535 |
| Pixel resolution | 64 dot × 32 dot | 32 dot × 32 dot | 48 dot × 48 dot |
| Max power consumption | 40W | 29W | 43W |
| Panel weight | 0.45KG | 0.35KG | 0.45KG |
Cabinet Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Cabinet size | 960mm×960mm×90mm | 576mm×576mm×90mm, 768mm×768mm×90mm | 960mm×960mm×90mm |
| Cabinet Resolution | 192 dot × 192 dot | 96 dot × 96 dot, 128dot×128dot | 144dot×144dot |
| Quantity of panel | 18pcs | 9pcs, 16pcs | 18pcs |
| Hub connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Diecast aluminum cabinet | Diecast aluminum cabinet | Diecast aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best viewing angle | 170/120 | 140/120 | 140/120 |
| Screen power supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max power capacity | 976W/m² | 1050W/m² | 1350W/m² |
| Average power | 488W/m² | 525W/m² | 675W/m² |
Technical Specifications
| Item | Outdoor P5 | Outdoor P6 | Outdoor P6.67 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/8S | 1/8S | 1/6S |
| Refresh frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920-3840 HZ/S |
| Display color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 5000-5500 mcd/m² | 4000-5000 cd/m² | 4000-5000 cd/m² |
| Life span | 100000 Hours | 100000 Hours | 100000 Hours |
| Control distance | < 100M | < 100M | < 100M |
| Best viewing distance | 5-40M | 6-40M | 6-40M |
| Operating temperature | -10°C ~ 45°C | -10°C ~ 45°C | -10°C ~ 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP protective index | IP65 | IP65 | IP65 |
Most in Kinglight and 3840 refresh rate, if need to change detail
More Pixel Pitch and technical details, feel free to contact us
More Pixel Pitch and technical details, feel free to contact us
